The MP-240 is a narrow and extremely agile personnel vehicle and heavy duty tug designed for long distances.
It’s also the most cost-efficient way to help supervisors and foremen cover distances two times faster than on foot.
It fits through door openings, into elevators and around tight corners with ease.
This low profile vehicle has a compact design and low center of gravity combined with user-friendly handlebar operation.
The easy-to-access battery compartment is located under the lift-up seat.
MP240 with OPTIONAL Canopy and PVC Curtains:
Motrec MP-240 burden carrier and Tug is shown with the optional full length canopy, featuring lightweight Lexan windscreen with pantograph windscreen wiper, roll down PVC clear vision curtains, rear vision mirrors and flashing light…. overall height 1850mm. Options include conditional registration kit of indicators and number plate light.
Dimensions:
| DIMENSIONS | 24V | 36V |
|---|---|---|
| VEHICLE | ||
| Weight | 218 kg (480lbs.) | 455 kg (1,000lbs.) |
| Height | 1016 mm (40″) | 1168 mm (46″) |
| Length | 1981 mm (78″) | 2007 mm (79″) |
| Width | 762 mm (30″) | 762 mm (30″) |
| Wheel Base | 1270 mm (50″) | 1448 mm (57″) |
| DECK | ||
| Deck Height | 635 mm (25″) | 635 mm (25″) |
| Deck Length | 508 mm (20″) | 508 mm (20″) |
| Deck width | 762 mm (30″) | 737 mm (29″) |
Specifications and standard equipment are subject to change without notice.
Specifications
| SPECIFICATIONS | 24V | 36V |
|---|---|---|
| POWERTRAIN | ||
| Motor | 6 hp shunt motor | 10 hp shunt motor |
| Drive Axle | Helical gear differential | Helical gear differential |
| Transmission | Direct drive | Direct drive |
| Controller | SEPEX Electronic speed controller | SEPEX Electronic speed controller |
| ENERGY | ||
| Voltage | 24V | 36V |
| Battery | Four 6V-232AH batteries | Six 6V-232AH batteries |
| Charger | High-frequency (85-265VAC / 45-65Hz, 1kw), built-in and automatic. | High-frequency (85-265VAC / 45-65Hz, 1kw), built-in and automatic. |
| CHASSIS | ||
| Body | 14-G diamond-plate steel body, tubular frame, powder coating. | 14-G diamond-plate steel body, tubular frame, powder coating. |
| Suspension | Dual coil springs & shock absorbers on front, dual coil springs and shock absorber on rear | Dual coil springs & shock absorbers on front, dual coil springs and shock absorber on rear |
| Brakes | Dual self-adjusting mechanical drum brakes on rear, hand lever parking brake | Dual self-adjusting mechanical drum brakes on rear, hand lever parking brake |
| Wheels | 4.8×8 LRC pneumatic tires | 4.8×8 LRC pneumatic tires |
| Steering | Handlebar | Handlebar |
| Seat | Bucket seat on slide adjusters | Bucket seat on slide adjusters |
| Lights | LED Headlight, Brakes & Tails | LED Headlight, Brakes & Tails |
| Indicators | Battery status indicator | Battery status indicator |
| Accessories | Bolt-on bumpers and rear wheel guards, 24V accessories to equalize cells and extend battery life. | Bolt-on bumpers and rear wheel guards, 36V accessories to equalize cells and extend battery life. |
| Safety | Reverse alarm, Deadman foot switch, Horn | Reverse alarm, Deadman foot switch, Horn |
