- A spacious 20.9-sq-ft cargo deck provides a large platform for catering supplies, event equipment or luggage.
- Two-passenger bench seating and a 1,200-lb total load capacity makes this ideal for housekeeping, food service or maintenance jobs.
- Standard headlights and taillights allow you to safely work early mornings and late nights.
- Choose between 13.5-hp gas or 48V electric options and get the powertrain that works for you.
SPECIFICATIONS
| Body & Chassis | |
|---|---|
| Frame | Welded Steel w/ E-Shield e-coat plus DuraShield™ Powder Coat |
| Body & Finish | Injection Molded TPO (Front) /Injection Molded PP (Rear) |
| Standard Color | Patriot Blue |
| Dimensions | |
| Overall Length | 141.0 in (358 cm) |
| Overall Width | 48.5 in (123 cm) |
| Overall Height | 48.6 in (123 cm) (w/o Roof) 72.0 in (183 cm) (w/ Struts & Roof) |
| Wheel Base | 93.5 in (237 cm) |
| Wheel Track | 34.2 in (87 cm) Front 38.0 in (97 cm) Rear |
| Ground Clearance | 4.3 in (11 cm) |
| Cargo Deck Capacity | 20.9-sq-ft (1.94 m2) |
| Power | |
| Power Source | 48V DC |
| Horsepower (KW) | 18.1 hp (13.5 kW) @ 1900 rpm |
| Electrical System | 48V |
| Battery (Qty/Type) | Eight, 6V Deep Cycle |
| Battery Charger | 48 V, 120V AC, UL/CSA |
| Key or Pedal Start | Pedal |
| Speed Controller | 400 Amp Precision Drive System (PDS) |
| Drive Train | Motor Shaft Direct Drive |
| Transaxle | Differential w/ Helical Gears |
| Gear Selection | Dash-Mounted Forward-Neutral-Reverse |
| Rear Axle Ratio | 14.7:1 |
| Performance | |
| Seating Capacity | 2-Person |
| Weight w/o Batteries | 810 lb (367 kg) |
| Curb Weight | 1300 lb (590 kg) |
| Vehicle Load Capacity | 1000 lb (454 kg) |
| Outside Clearance Circle | 25.5 ft (7.8 m) |
| Speed | 13 mph +/- 0.5 mph (21 kph +/-0.8 kph) |
| Steering & Suspension | |
| Steering | Self-Compensating Rack & Pinion |
| Suspension | Leaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear) |
| Service Brake | Rear Wheel Mechanical, Self-Adjusting Drum |
| Parking Brake | Self-Compensating,Single-Point Engagement |
| Tires | Links 18 x 8.5 – 8 (4 Ply Rated) |
